12 Installation, Support, and Maintenance Guide
Evolution X1 Satellite Router
X1 Router (Indoor) Specifications
Typical Transmit and Receive
Phase Noise (dBc/Hz) at:
Typical Phase Jitter at
14 KHz to 1 MHz
 1.8 rms
Transmit Carrier Suppression  40 dBc (MAX)
Discrete Spurs, harmonics and
non-harmonics
 50 dBc, with output  -15 dBm Inband 32 dBc
Modulator Spectral Shaping DVB-S2 (ETSI EN302307)
Transmitter On/Off  50 dBc, with output power  -15 dBm
Frequency Range
Transmit
Receive
950-1700 MHz
950-2150 MHz
Table 3-3. X1 Router (Indoor) RF Specifications (continued)
Category Description
Frequency Phase Noise
1 KHz -75
10 KHz -85
100 KHz -95
