IEI Technology AFL-HM55 Series User Manual

AFL-HM55 Series Panel PC
Page 7
1.3 Internal Overview
The AFL-HM55 Series has the following components installed internally:
 1 x Mainboard
 1 x 2.0 GB 800/1066 MHz DDR3 dual-channel SO-DIMM
 1 x Wireless module
 1 x Bluetooth module
1.4 System Specifications
The technical specifications for the AFL-HM55 Series systems are listed in Table 1-1.
Specification 15i 15iE 17i 19i
LCD Size 15” 15” 17” 19”
Max. Resolution 1024 x 768 1024 x 768 1280 x 1024 1280 x 1024
Contrast Ratio 350 250 350 450
Brightness (cd/m
2
) 700:1 450:1 800:1 1000:1
LCD Color 16.2 M 16.2 M 16.7 M 16.7 M
Pixel Pitch (H x V) (mm) 0.297 0.297 0.264 0.294
Viewing Angle (H-V) 140
。
/ 125
。
120
。
/ 100
。
160
。
/ 160
。
178
。
/ 178
。
Backlight MTBF 50,000 hours 40,000 hours 50,000 50,000
SBC Model AFLMB2-HM55
CPU Intel® Celeron P4500 1.86G CPU
Intel® Core™ i3-330M 2.26G CPU
Intel® Core™ i5-520M 2.4G CPU
Intel® Core™ i7-620M 2.66G CPU
Chipset Intel HM55 (Calpella)
Memory Two 204-pin 800 / 1066 DDR3 dual-channel SO-DIMM (system max. 8GB)
LAN Controller Realtek RTL8111E
Audio Codec ALC888 + TPA2012 2.1w/ch CLASS D amplifier
Speaker AMP 3 W + AMP 3 W (built-in stereo speakers)
SSD One SATA DOM card slot
Watchdog Timer Software Programmable supports 1 sec. ~ 255 sec. system reset
1 x PCIe mini card (wireless LAN 802.11 b/g/n module) Expansion
1 x Bluetooth module (internal USB interface, Bluetooth v 2.1+EDR)
