IEI Technology AFL-HM55 Series User Manual

AFL-HM55 Series Panel PC
Page 60
5.2 Main
The Main BIOS menu (5BIOS Menu 1) appears when the BIOS Setup program is entered.
The Main menu gives an overview of the basic system information.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
BIOS Information
BIOS Vendor American Megatrends
Core Version 4.6.3.7 0.16
Project Version H615AR10.ROM
Build Date 10/12/2010 15:39:09
Memory Information
Total Memory 1024 MB (DDR3 1066)
System Date [Wed 04/20/2011]
System Time [14:27:27]
Access Level Administrator
Set the Date. Use Tab to
switch between Date
elements.
----------------------
 : Select Screen
 : Select Item
Enter Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 1: Main
 System Overview
The System Overview lists a brief summary of different system components. The fields in
System Overview cannot be changed. The items shown in the system overview include:
 BIOS Vendor: Installed BIOS vendor
 Core Version: Current BIOS version
 Project Version: The board version
 Build Date: Date the current BIOS version was made
 Access Level: User access level
 Memory Information
The Memory Information lists a brief summary of the on-board memory. The fields in
Memory Information cannot be changed.
 Total Memory: Displays the auto-detected system memory size and type.
