 Printer mode
 EPP-1.7 and SPP Mode
 ECP and EPP 1.7 Mode
5.3.7 H/W Monitor
The H/W Monitor menu (BIOS Menu 10) shows the operating temperature, fan speeds
and system voltages.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
PC Health Status
CPU Temperature :+91 C
SYS Temperature :+58 C
CPU FAN Speed :4702 RPM
SYS FAN Speed :3722 RPM
VCC3C :+3.360 V
V_core :+1.192 V
+5V :+5.045 V
+12V :+12.056 V
+1.5V :+1.520 V
VSB3V :+3.360 V
VBAT :+3.280 V
---------------------
 : Select Screen
 : Select Item
Enter Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 10: Hardware Health Configuration
 PC Health Status
The following system parameters and values are shown. The system parameters that are
monitored are:
 System Temperatures:
o CPU Temperature
o System Temperature
 Fan Speeds:
o CPU Fan Speed
o System Fan Speed
 Voltages:
