AFL-HM55 Series Panel PC

Page 36

Figure 3-13: iTPM Jumper Location

3.9.10 ME RTC Select Jumper

Jumper Label:

ME_RTC1

Jumper Type:

3-pin header

Jumper Settings:

See Table 3-13

Jumper Loc

ation:

See Figure 3-14

The ME RT

C select jumper settings are shown in Table 3-13.

ME RTC select Description

Short 1-2 Keep ME RTC

Short 2-3 Clear ME RTC

Table 3-13: ME RTC Jumper Settings

The ME RTC jumper location is shown in Figure 3-14.
