IEI Technology AFL-HM55 Series User Manual

AFL-HM55 Series Panel PC
Page 38
Figure 3-15: SPI Jumper Location
3.10 Mounting the System
WARNING!
When mounting the flat panel PC onto an arm, onto the wall or onto a
panel, it is better to have more than one person to help with the installation
to make sure the panel PC does not fall down and get damaged.
The four methods of mounting the AFL-HM55 Series are listed below.
 Wall mounting
 Panel mounting
 Arm mounting
 Rack mounting
The four mounting methods are described below.
3.10.1 Wall Mounting
To mount the flat panel PC onto the wall, please follow the steps below.
Select the location on the wall for the wall-mounting bracket.
