AFL-HM55 Series Panel PC

Page 35

Figure 3-12: ME Debug Mode Jumper Location

3.9.9 iTPM Setting Jumper

Jumper Label:

J_ITPM1

Jumper Type:

3-pin header

Jumper Settings:

See Table 3-12

Jumper Loc

ation:

See Figure 3-13

The iTPM ju

mper settings are shown in Table 3-12.

iTPM setting Description

Short 1-2 Disable iTPM

Short 2-3 Enable iTPM

Table 3-12: iTPM Jumper Settings

The iTPM jumper location is shown in Figure 3-13.
