IEI Technology AFL-HM55 Series User Manual

AFL-HM55 Series Panel PC
Page 77

Enabled DEFAULT
The onboard High Definition Audio controller
automatically detected and enabled
 Set Spread Spectrum [Disabled]
Use the Set Spread Spectrum option to enable or disable the Set Spread Spectrum
function.

Disabled DEFAULT
Set Spread Spectrum is disabled

Enabled
Set Spread Spectrum is enabled
5.4.3 Intel IGD SWSCI OpRegion
Use the Intel IGD SWSCI OpRegion menu (BIOS Menu 15) to configure the video device
connected to the system.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Chipset
Intel IGD SWSCI OpRegion Configuration
DVMT/FIXED Memory [Maximum]
Active LFP [Enable LVDS]
LCD Panel Type [800x600 18bit]
Select DVMT/FIXED Mode
Memory size used by
Internal Graphics Device
---------------------
 : Select Screen
 : Select Item
Enter Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 15: Intel IGD SWSCI OpRegion
 DVMT/FIXED Memory [Maximum]
Use the DVMT/FIXED Memory option to specify the maximum amount of memory that
can be allocated as graphics memory. Configuration options are listed below.
 128 MB
