IEI Technology AFL-HM55 Series User Manual

AFL-HM55 Series Panel PC
Page 66

Compatible DEFAULT
Configures the on-board SATA controller to be in
compatible mode. In this mode, a SATA channel will
replace one of the IDE channels. This mode supports
up to 6 storage devices.
5.3.5 USB Configuration
Use the USB Configuration menu (BIOS Menu 7) to read USB configuration information
and configure the USB settings.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
USB Configuration
USB Devices:
1 Keyboard, 2 Hubs
All USB Devices [Enabled]
Legacy USB Support [Enabled]
Enable / Disable All USB
Devices
---------------------
 : Select Screen
 : Select Item
Enter Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 7: USB Configuration
 USB Devices
The USB Devices Enabled field lists the USB devices that are enabled on the system
 All USB Devices [Enabled]
Use this option to enable or disable all USB device support on the system.

Disabled
All USB device support disabled

Enabled DEFAULT
All USB device support enabled
