IEI Technology AFL-HM55 Series User Manual

AFL-HM55 Series Panel PC
Page 79
5.5 Boot
Use the Boot menu (BIOS Menu 16) to configure system boot options.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
Boot Configuration
Quiet Boot [Enabled]
Bootup NumLock State [On]
Realtek 8111E PXE OpROM [Disabled]
Boot Option Priorities
Enables/Disables Quiet
Boot option
---------------------
 : Select Screen
 : Select Item
Enter Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 16: Boot
 Quiet Boot [Enabled]
Use the Quiet Boot BIOS option to select the screen display when the system boots.

Disabled
Normal POST messages displayed

Enabled DEFAULT
OEM Logo displayed instead of POST messages
 Bootup NumLock State [On]
Use the Bootup NumLock State BIOS option to specify if the number lock setting must
be modified during boot up.

On DEFAULT
Allows the Number Lock on the keyboard to be
enabled automatically when the computer system
boots up. This allows the immediate use of the
10-key numeric keypad located on the right side of
the keyboard. To confirm this, the Number Lock LED
light on the keyboard is lit.
