5.3.4 SATA Configuration
Use the SATA Configuration menu (BIOS Menu 6) to change and/or set the
configuration of the SATA devices installed in the system.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
SATA Configuration
SATA Port0 Not Present
SATA Port1 Not Present
SATA Port2 Not Present
SATA Mode [IDE Mode]
Serial-ATA Controller 0 [Compatible]
Serial-ATA Controller 1 [Enhanced]
(1) IDE Mode. (2) AHCI
Mode.
---------------------
 : Select Screen
 : Select Item
Enter Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 6: IDE Configuration
 SATA Mode [IDE Mode]
Use the SATA Mode option to configure SATA devices as normal IDE devices.

Disable
Disables SATA devices.

IDE Mode DEFAULT
Configures SATA devices as normal IDE device.

AHCI Mode
Configures SATA devices as AHCI device.
 Serial-ATA Controller n [Compatible]
Use the Serial-ATA Controller option to configure the SATA controller.

Disabled
Disables the on-board SATA controller.

Enhanced
Configures the on-board SATA controller to be in
Enhanced mode. In this mode, IDE channels and SATA
channels are separated.
