IEI Technology AFL-HM55 Series User Manual

AFL-HM55 Series Panel PC
Page 68
5.3.6.1 Serial Port n Configuration
Use the Serial Port n Configuration menu (BIOS Menu 9) to configure the serial port n.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
Serial Port 0 Configuration
Serial Port [Enabled]
Device Settings IO=3F8h; IRQ=4
Change Settings [Auto]
E
nable or Disable Serial
Port (COM)
---------------------
 : Select Screen
 : Select Item
Enter Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 9: Serial Port n Configuration Menu
5.3.6.1.1 Serial Port 0 Configuration
 Serial Port [Enabled]
Use the Serial Port option to enable or disable the serial port.

Disabled
Disable the serial port

Enabled DEFAULT
Enable the serial port
 Change Settings [Auto]
Use the Change Settings option to change the serial port IO port address and interrupt
address.

Auto DEFAULT
The serial port IO port address and interrupt address
are automatically detected.

IO=3F8h;
IRQ=4
Serial Port I/O port address is 3F8h and the interrupt
address is IRQ4
