AFL-HM55 Series Panel PC

Page 23

Figure 3-3: HDD Installation

Replace the HDD cover and secure using one (1) retention screw.

3.7 Removing the Rear Panel Cover

WARNING:

Over-tightening rear cover screws will crack the plastic frame.

Maximum torque for cover screws is 5 kg-cm (0.36 lb-ft/0.49 Nm).

To access the AFL-HM55 internally, the rear panel cover must first be removed. To remove

the rear panel cover, please follow the steps below.

Remove twenty-one (21) retention screws from the rear panel cover. See Figure 3-4.
