IEI Technology AFL-HM55 Series User Manual

AFL-HM55 Series Panel PC
Page 24
Figure 3-4: AFL-HM55 Series Back Cover Retention Screws
Lift the cover off the AFL-HM55 Series panel PC.
3.8 Removing the Internal Aluminum Cover
WARNING:
Over-tightening rear cover screws will crack the plastic frame.
Maximum torque for cover screws is 5 kg-cm (0.36 lb-ft/0.49 Nm).
To remove the internal aluminum cover, follow the steps below.
Remove sixteen (16) retention screws securing the internal aluminum cover.
Figure 3-5 sh
ows the aluminum cover retention screws of the AFL-HM55 Series.
