ACCEPTANCE TESTING
7-36 46882/439
Table 7-6 ALC linearity at 500 MHz
RF level (dBm) RF level min.
(dBm)
Result (dBm)
src A src B (src C)
RF level
max. (dBm)
−4 −4.8
____ ____ ____
−3.2
−3 −3.8
____ ____ ____
−2.2
−2 −2.8
____ ____ ____
−1.2
−1 −1.8
____ ____ ____ 0.2
0
−0.8
____ ____ ____ +0.8
1 0.2 ____ ____ ____ +1.8
2 +1.2 ____ ____ ____ +2.8
3 +2.2 ____ ____ ____ +3.8
4 +3.2 ____ ____ ____ +4.8
5 +4.2 ____ ____ ____ +5.8
6 +5.2 ____ ____ ____ +6.8
7 +6 ____ ____ ____ +8
8 +7 ____ ____ ____ +9
9 +8 ____ ____ ____ +10
10 +9 ____ ____ ____ +11
11 +10 ____ ____ ____ +12
12 +11 ____ ____ ____ +13
12.1 +11.1 ____ ____ ____ +13.1
12.2 +11.2 ____ ____ ____ +13.2
12.3 +11.3 ____ ____ ____ +13.3
12.4 +11.4 ____ ____ ____ +13.4
12.5 +11.5 ____ ____ ____ +13.5
12.6 +11.6 ____ ____ ____ +13.6
12.7 +11.7 ____ ____ ____ +13.7
12.8 +11.8 ____ ____ ____ +13.8
12.9 +11.9 ____ ____ ____ +13.9
13 +12 ____ ____ ____ +14
14 +13 ____ ____ ____ +15
15 +14 ____ ____ ____ +16
16 +15 ____ ____ ____ +17
17 +16 ____ ____ ____ +18
18 +17 ____ ____ ____ +19
19 +18 ____ ____ ____ +20
20 +19 ____ ____ ____ +21
21 +20 ____ ____ ____ +22
22 +21 ____ ____ ____ +23
23 +22 ____ ____ ____ +24
24 +23 ____ ____ ____ +25
