ACCEPTANCE TEST RESULTS TABLES
46882/439 7-37
Table 7-7 ALC linearity at 2400 MHz
RF level (dBm) RF level min.
(dBm)
Result (dBm)
src A src B (src C)
RF level max.
(dBm)
−4 −5.6
____ ____ ____
−2.4
−3 −4.6
____ ____ ____
−1.4
−2 −3.6
____ ____ ____
−0.4
−1 −2.6
____ ____ ____ +0.6
0
−1.6
____ ____ ____ +1.6
1
−0.6
____ ____ ____ +2.6
2 0.4 ____ ____ ____ +3.6
3 +1.4 ____ ____ ____ +4.6
4 +2.4 ____ ____ ____ +5.6
5 +3.4 ____ ____ ____ +6.6
6 +4.4 ____ ____ ____ +7.6
7 +5 ____ ____ ____ +9
8 +6 ____ ____ ____ +10
9 +7 ____ ____ ____ +11
10 +8 ____ ____ ____ +12
11 +9 ____ ____ ____ +13
12 +10 ____ ____ ____ +14
12.1 +10.1 ____ ____ ____ +14.1
12.2 +10.2 ____ ____ ____ +14.2
12.3 +10.3 ____ ____ ____ +14.3
12.4 +10.4 ____ ____ ____ +14.4
12.5 +10.5 ____ ____ ____ +14.5
12.6 +10.6 ____ ____ ____ +14.6
12.7 +10.7 ____ ____ ____ +14.7
12.8 +10.8 ____ ____ ____ +14.8
12.9 +10.9 ____ ____ ____ +14.9
13 +11 ____ ____ ____ +15
14 +12 ____ ____ ____ +16
15 +13 ____ ____ ____ +17
16 +14 ____ ____ ____ +18
17 +15 ____ ____ ____ +19
18 +16 ____ ____ ____ +20
19 +17 ____ ____ ____ +21
20 +18 ____ ____ ____ +22
