IFR 2026 User Manual

ACCEPTANCE TESTING
7-38 46882/439
Table 7-8 Attenuator test at 2.6 MHz
RF level (dBm) RF level min.
(dBm)
Result (dBm)
src A src B (src C)
RF level max.
(dBm)
0
−0.8
____ ____ ____ +0.8
−4.1 −4.9
____ ____ ____
−3.3
−15.1 −15.9
____ ____ ____
−14.3
−26.1 −26.9
____ ____ ____
−25.3
−37.1 −37.9
____ ____ ____
−36.3
−48.1 −48.9
____ ____ ____
−47.3
−59.1 −59.9
____ ____ ____
−58.3
−70.1 −70.9
____ ____ ____
−69.3
−81.1 −81.9
____ ____ ____
−80.3
−92.1 −92.9
____ ____ ____
−91.3
−103.1 −103.9
____ ____ ____
−102.3
−114.1 −114.9
____ ____ ____
−113.3
Table 7-9 Attenuator test at 540.1 MHz
RF level (dBm) RF level min.
(dBm)
Result (dBm)
src A src B (src C)
RF level max.
(dBm)
0
−0.8
____ ____ ____ +0.8
−4.1 −4.9
____ ____ ____
−3.3
−15.1 −15.9
____ ____ ____
−14.3
−26.1 −26.9
____ ____ ____
−25.3
−37.1 −37.9
____ ____ ____
−36.3
−48.1 −48.9
____ ____ ____
−47.3
−59.1 −59.9
____ ____ ____
−58.3
−70.1 −70.9
____ ____ ____
−69.3
−81.1 −81.9
____ ____ ____
−80.3
−92.1 −92.9
____ ____ ____
−91.3
−103.1 −103.9
____ ____ ____
−102.3
−114.1 −114.9
____ ____ ____
−113.3
