IFR 2026 User Manual

ACCEPTANCE TEST RESULTS TABLES
46882/439 7-39
Table 7-10 Attenuator test at 1140.1 MHz
RF level (dBm) RF level min.
(dBm)
Result (dBm)
src A src B (src C)
RF level max.
(dBm)
0
−0.8
____ ____ ____ +0.8
−4.1 −4.9
____ ____ ____
−3.3
−15.1 −15.9
____ ____ ____
−14.3
−26.1 −26.9
____ ____ ____
−25.3
−37.1 −37.9
____ ____ ____
−36.3
−48.1 −48.9
____ ____ ____
−47.3
−59.1 −59.9
____ ____ ____
−58.3
−70.1 −70.9
____ ____ ____
−69.3
−81.1 −81.9
____ ____ ____
−80.3
−92.1 −92.9
____ ____ ____
−91.3
−103.1 −103.9
____ ____ ____
−102.3
−114.1 −114.9
____ ____ ____
−113.3
Table 7-11 Attenuator test at 1740.1 MHz
RF level (dBm) RF level min.
(dBm)
Result (dBm)
src A src B (src C)
RF level max.
(dBm)
0
−1.6
____ ____ ____ +1.6
−4.1 −5.7
____ ____ ____
−2.5
−15.1 −16.7
____ ____ ____
−13.5
−26.1 −27.7
____ ____ ____
−24.5
−37.1 −38.7
____ ____ ____
−35.5
−48.1 −49.7
____ ____ ____
−46.5
−59.1 −60.7
____ ____ ____
−57.5
−70.1 −71.7
____ ____ ____
−68.5
−81.1 −82.7
____ ____ ____
−79.5
−92.1 −93.7
____ ____ ____
−90.5
−103.1 −104.7
____ ____ ____
−101.5
−114.1 −115.7
____ ____ ____
−112.5
