IFR 2026 User Manual

ACCEPTANCE TESTING
7-40 46882/439
Table 7-12 Attenuator test at 2399 MHz
RF level (dBm) RF level min.
(dBm)
Result (dBm)
src A src B (src C)
RF level max.
(dBm)
0
−1.6
____ ____ ____ +1.6
−4.1 −5.7
____ ____ ____
−2.5
−15.1 −16.7
____ ____ ____
−13.5
−26.1 −27.7
____ ____ ____
−24.5
−37.1 −38.7
____ ____ ____
−35.5
−48.1 −49.7
____ ____ ____
−46.5
−59.1 −60.7
____ ____ ____
−57.5
−70.1 −71.7
____ ____ ____
−68.5
−81.1 −82.7
____ ____ ____
−79.5
−92.1 −93.7
____ ____ ____
−90.5
−103.1 −104.7
____ ____ ____
−101.5
−114.1 −115.7
____ ____ ____
−112.5
Table 7-13 Alternative attenuator functional test at 10 MHz
Attenuator pad Measured value (dB)
src A src B (src C)
33 dB ____ ____ ____
22 dB ____ ____ ____
33 dB ____ ____ ____
11 dB ____ ____ ____
33 dB ____ ____ ____
