CAMERA SETTINGS and ADJUSTMENT
5.2 Settings from the Menu
■
ENGINEER (1/2)
Menu Item
Initial
Setting
Setting Value Description, Remarks
MENU DATA
ALL VF
Mode which executes a optical transmission without power
transmission from BS/CCU and with local power for the
power supply to the camera.
FIBER SINGLE MODE CONT
SINGLE MODE
OFF OFF, ON
If it is sets to "ON," the mode is switched to the single fiber
mode.
✔ ‐
CAMERA ID SETUP
―
PROGRAM NO.
1 1 to 99, OFF
You can set the camera No. for program number display.
If the camera No. is set on the Remote control panel side,
the ID No. that has been set is displayed.
If the camera No. is set on the camera side, the ID No. that
has been set is displayed on the Remote control panel.
‐ ‐
―
ID NO
1 1 to 40
Sets ID No. of camera. Set this when you want the camera
No. to be detected and displayed on the CCU/BS side.
‐ ‐
DIMMER
OFF OFF, ON
Adjust the brightness of the LED display of the camera
number on the front and back of the camera.
OFF : LED display is normal brightness.
ON : The LED indication becomes darker than usual.
✔ ‐
MATRIX PRESET DATA
―
MATRIX 1
SMPTE
OFF, SMPTE, EBU,
BT.709, BT.2020,
(USER1, USER2)
Selects the preset of color matrix.
* The preset data settings of USER 1 and 2 are operated
on the "MATRIX USER 1 DATA SET" and "MATRIX
USER 2 DATA SET" screens, respectively.
✔ ‐
―
MATRIX 2
EBU
OFF, SMPTE, EBU,
BT.709, BT.2020,
(USER1, USER2)
✔ ‐
MATRIX 3
BT.709
OFF, SMPTE, EBU,
BT.709, BT.2020,
(USER1, USER2)
✔ ‐
MATRIX USER1 DATA SET
Sets the preset (USER1) of color matrix.
―
DATA SET MODE
OFF OFF, ON
ON : Sets the preset data.
OFF : Does not set the preset data.
‐ ‐
―
R-G
0.0 -100 to +100 Sets the matrix of R-G.
‐ ‐
―
R-B
0.0 -100 to +100 Sets the matrix of R-B.
‐ ‐
―
G-R
0.0 -100 to +100 Sets the matrix of G-R.
‐ ‐
―
G-B
0.0 -100 to +100 Sets the matrix of RG-B.
‐ ‐
―
B-R
0.0 -100 to +100 Sets the matrix of B-R.
‐ ‐
―
B-G
0.0 -100 to +100 Sets the matrix of B-G.
‐ ‐
DATA CLEAR
--- READY
READY : Update standby state.
PUSH SET
→
CLR : Clears the preset data.
CANCEL : Exit "DATA CLEAR" without clearing
the settings.
‐ ‐
MATRIX USER2 DATA SET
Sets the preset (USER2) of color matrix.
―
DATA SET MODE
OFF OFF, ON
ON : Sets the preset data.
OFF : Does not set the preset data.
- -
―
R-G
0.0 -100 to +100 Sets the matrix of R-G.
‐ ‐
―
R-B
0.0 -100 to +100 Sets the matrix of R-B.
‐ ‐
―
G-R
0.0 -100 to +100 Sets the matrix of G-R.
‐ ‐
―
G-B
0.0 -100 to +100 Sets the matrix of RG-B.
‐ ‐
―
B-R
0.0 -100 to +100 Sets the matrix of B-R.
‐ ‐
―
B-G
0.0 -100 to +100 Sets the matrix of B-G.
‐ ‐
DATA CLEAR
--- READY
READY : Update standby state.
PUSH SET
→
CLR : Clears the preset data.
CANCEL : Exit "DATA CLEAR" without clearing
the settings.
- -
INCOM SETUP (ENG)
―
HEADSET
―
INCOM1
DYNAMIC CARBON, DYNAMIC It selects the type of microphone of INCOM1.
✔ ‐
―
INCOM1 POWER
OFF OFF, ON
It sets the power supply ON/OFF to the microphone of
INCOM1.
It is fixed to ON when the CARBON setting is selected.
✔ ‐
―
INCOM1 GAIN
NORMAL NORMAL, HI
When INCOM1 is set to CARBON, it sets GAIN of the
microphone of INCOM1.
✔ ‐
―
INCOM2
DYNAMIC CARBON, DYNAMIC It selects the type of microphone of INCOM2.
✔ ‐
―
INCOM2 POWER
OFF OFF, ON
It sets the power supply ON/OFF to the microphone of
INCOM2.
It is fixed to ON when the CARBON setting is selected.
✔ ‐
INCOM2 GAIN
NORMAL NORMAL, HI
When INCOM2 is set to CARBON, it sets GAIN of the
microphone of INCOM2.
✔ ‐
To Next Page
