5.2 Settings from the Menu
Menu Item
Initial
Setting
Setting Value Description, Remarks
MENU DATA
ALL VF
―
RECEIVE
―
INCOM1 L/R CH
It allocates the receive channel LEFT/RIGHT of the
INCOM1 line.
―
INCOM1
BOTH BOTH, LEFT, RIGHT
It sets the allocation of the head set receive channel of the
INCOM1 line.
✔ ‐
―
INCOM2
BOTH BOTH, LEFT, RIGHT
It sets the allocation of the head set receive channel of the
INCOM2 line.
✔ ‐
―
PGM1
BOTH BOTH, LEFT, RIGHT
It sets the allocation of the head set receive channel of the
PGM1 line.
✔ ‐
―
PGM2
BOTH BOTH, LEFT, RIGHT
It sets the allocation of the head set receive channel of the
PGM2 line.
✔ ‐
―
INCOM2 L/R CH
It allocates the receive channel LEFT/RIGHT of the
INCOM2 line.
―
INCOM1
BOTH BOTH, LEFT, RIGHT
It sets the allocation of the head set receive channel of the
INCOM1 line.
✔ ‐
―
INCOM2
BOTH BOTH, LEFT, RIGHT
It sets the allocation of the head set receive channel of the
INCOM2 line.
✔ ‐
―
PGM1
BOTH BOTH, LEFT, RIGHT
It sets the allocation of the head set receive channel of the
PGM1 line.
✔ ‐
PGM2
BOTH BOTH, LEFT, RIGHT
It sets the allocation of the head set receive channel of the
PGM2 line.
✔ ‐
―
EARPHONE
―
INCOM1
ON OFF, ON
ON : INCOM1 is output from the EARPHONE connector.
✔ ‐
―
INCOM2
OFF OFF, ON
ON : INCOM2 is output from the EARPHONE connector.
✔ ‐
PGM SELECT
OFF OFF, INC1, INC2
INC1 : PGM1 and PGM2 are output from the EARPHONE
connector, and the volume can be controlled by
using the INCOM1 PGM volume.
INC2 : PGM1 and PGM2 are output from the EARPHONE
connector, and the volume can be controlled by
using the INCOM2 PGM volume.
✔ ‐
―
INCOM MODE
NORMAL
NORMAL, CROSS,
1LINE ENG, USA,
USER1, USER2
It selects the operation mode of the INCOM line (preset
setting).
‐ ‐
Sets the connection for when USER1/USER2 is selected in
INCOM MODE PRESET.
―
INCOM MODE SETUP
―
DATA LOAD
READY
READY, NORMAL,
CROSS, 1LINE ENG,
USA, USER1, USER2,
CANCEL
It reads the setting data to be referred to.
‐ ‐
―
INCOM1 MIX
ENG
OFF, ENG, PRD, BOTH,
SW LINK
Selects the line such that whether LISTEN line of INCOM1
is linked to ENG line, PROD line, both lines, or SW on the
back side, etc.
*4
✔ ‐
―
INCOM2 MIX
PRD
OFF, ENG, PRD, BOTH,
SW LINK
Selects the line such that whether LISTEN line of INCOM2
is linked to ENG line, PROD line, both lines, or SW on the
back side, etc.
*4
✔ ‐
―
INCOM1 -> INCOM2
OFF OFF, ON
It enables listening to LISTEN line of INCOM1 by using
INCOM2.
✔ ‐
―
INCOM1 <- INCOM2
OFF OFF, ON
It enables listening to LISTEN line of INCOM2 by using
INCOM1.
✔ ‐
―
AFTER VR MIX
It is a setting that mixes the LISTEN line after controlling
the volume by using the INCOM volume.
Therefore, the volumes of the MIXed LISTEN lines cannot
be changed simultaneously.
―
INCOM1 -> INCOM2
OFF OFF, ON
It enables listening to LISTEN of INCOM1 by using
INCOM2.
The volume of MIXed INCOM1 can be controlled by using
the INCOM1 volume.
✔ ‐
―
INCOM1 <- INCOM2
OFF OFF, ON
It enables listening to LISTEN of INCOM2 by using
INCOM1.
The volume of MIXed INCOM2 can be controlled by using
the INCOM2 volume.
✔ ‐
DATA SAVE
READY USER1, USER2, CANCEL Saves data as USER1 or USER2.
‐ ‐
―
PGM FRONT VR
PGM1 PGM1, PGM2
It selects a PGM number to control by using the INCOM
PGM control dial on the right side of the camera.
However, PGM1 or PGM2 is selected from the line selected
with the INCOM SEL switch on the back of the camera.
✔ ‐
―
PGM SETUP
―
PGM LEVEL
LOW NORMAL, LOW
Sets the output level of PGM. (Reduced by 10 dB with LOW)
✔ ‐
―
PGM2 OUT PGM2
ON OFF, ON It sets whether or not the PGM2 signal is output to PGM2.
✔ ‐
―
PGM2 OUT PGM3
OFF OFF, ON It sets whether or not the PGM3 signal is output to PGM2.
✔ ‐
―
PGM2 OUT MIC1
OFF
OFF, ON It sets whether or not the MIC1 signal is output to PGM2.
✔ ‐
PGM2 OUT MIC2
OFF OFF, ON It sets whether or not the MIC2 signal is output to PGM2.
✔ ‐
