97
HDK-99 1803 VER1 (E)
5
CAMERA SETTINGS and ADJUSTMENT
5.2 Settings from the Menu
Menu Item
Initial
Setting
Setting Value Description, Remarks
MENU DATA
ALL VF
―
BELT PACK(OPTION)
―
INCOM1 B.P
OFF OFF, ON Turns on when the belt pack is connected to INCOM1.
✔ ‐
INCOM2 B.P
OFF OFF, ON Turns on when the belt pack is connected to INCOM2.
✔ ‐
When setting the INCOM SUB board (option),sets the
signal output to PHONE/UTILITY.
―
UTILITY SET(OPTION)
―
INCOM1 LISTEN
OFF ON, OFF
Sets the ON/OFF for outputting fixed level INCOM1 signal
to PHONE/UTILITY.
✔ ‐
―
INCOM2 LISTEN
OFF ON, OFF
Sets the ON/OFF for outputting fixed level INCOM2 signal
to PHONE/UTILITY.
✔ ‐
―
INCOM1 TALK
OFF ON, OFF
Sets the ON/OFF of the talk line from UTILITY to
INCOM1 → CCU/BS.
✔ ‐
―
INCOM2 TALK
OFF ON, OFF
Sets the ON/OFF of the talk line from UTILITY to
INCOM2 → CCU/BS.
✔ ‐
―
OUTPUT LEVEL
0dB
+4dB, 0dB, -20dB,
VR SET(INCOM_SUB VR1)
Sets the output level of PHONE/UTILITY OUT.
✔ ‐
―
INPUT LEVEL
UNBALANCE
UNBALANCE, VR SET
Sets the signal level of the UTILITY input.
UNBALANCE (0dB), VR SET (INCOM_SUB VR2).
✔ ‐
INPUT
BALANCE
UNBALANCE,
BALANCE
Set the signal type of UTILITY input.
UNBALANCE (0dB), BALANCE (-16dB)
✔ ‐
It sets the PGM signal to the PGM output connector (option).
When the PGM output-only connector (option) is provided
on the rear side of the camera, it sets which PGM signal is
allocated to PGM1 or PGM 2 line.
PGM OUT SET(OPTION)
―
LEVEL
-20dB +4dB, 0dB, -20dB
Sets the output level of the PGM OUT signal.
✔ ‐
―
PGM OUT-1 PGM1
OFF ON, OFF Sets whether to output PGM 1 signal to PGM OUT - 1.
✔ ‐
―
PGM OUT-1 PGM2
OFF ON, OFF Sets whether to output PGM 2 signal to PGM OUT - 1.
✔ ‐
―
PGM OUT-1 PGM3
OFF ON, OFF Sets whether to output PGM 3 signal to PGM OUT - 1.
✔ ‐
―
PGM OUT-2 PGM1
OFF ON, OFF Sets whether to output PGM 1 signal to PGM OUT - 2.
✔ ‐
―
PGM OUT-2 PGM2
OFF ON, OFF Sets whether to output PGM 2 signal to PGM OUT - 2.
✔ ‐
PGM OUT-2 PGM3
OFF ON, OFF Sets whether to output PGM 3 signal to PGM OUT - 2.
✔ ‐
ENGINEER SET FILE RENEW
DATA RENEW MODE
Saves the conditions of camera level adjustment and menu.
The saved data can be loaded as user settings data of
"PRESET FILE LOAD" in MENU(3/4).
‐ ‐
*4 : Selection switch on the rear panel of the MIC line typically controls only the TALK line, but SW LINK to be selected TALK line and LISTEN line both can be
controlled.
