98
HDK-99 1803 VER1 (E)
5.2 Settings from the Menu
■
ENGINEER (2/2)
Menu Item
Initial
Setting
Setting Value Description, Remarks
MENU DATA
ALL VF
PROCESS ENABLE
COLOR CORR
ENABLE ENABLE, DISABLE
ENABLE : Enables control from the control panel.
DISABLE : Disables control from the control panel (Also
disables ON/OFF of processing and analog
control.)
✔ ‐
VF CONT
RETURN ON CONT
ON ON, OFF
Sets whether the RETURN control signal is sent to VF or
not.
When set to ON, zooming linked peaking of VF will not
work when RETURN is ON.
✔ ‐
VIDEO MAINTENANCE MODE
―
COLOR FILTER
LPF4 LPF1, LPF2, LPF3, LPF4
It sets the frequency band of the color-difference signal (Pb,
Pr) of the HD SDI signal.
LPF1 is the narrow band. The band width increases
sequentially in LPF2 and LPF3, and LPF4 (standard value)
has the widest band.
✔ ‐
Q-TV MODE(50Hz)
9MHz x 1ch
6MHz×2ch, 9MHz×1ch,
4.5MHz×2ch
Sets the Q-TV transmission mode when the operation
frequency is 50 Hz. Fixed to 2 ch when the operation
frequency is 59.94 Hz.
It is valid only when connected to BS/CCU corresponding
to Q-TV 2 system input.
✔ ‐
HD SDI TRUNK SETTING
EMB .AUDIO OUT
OFF OFF, ON
Sets the addition of EMB. AUDIO signal to HD-SDI
TRUNK signal. However, this can be selected only when
FA-97A is connected.
It is not operable with "---" indication when it is not
connected to FA-97A.
✔ ‐
OPTICAL ABERRATION CORR.
―
CORRECTION
ENABLE
ENABLE, DISABLE,
NONCOP.LENS
Switches Enable/Disable of aberration correction.
This setting is also saved when the power is turned off.
Therefore, set it to DISABLE if aberration correction is not
used.
✔ ‐
―
CORR. LEVEL R
0 -10 to 10 Controls the level of correction degree (R channel).
✔ ‐
CORR. LEVEL B
0 -10 to 10 Controls the level of correction degree (B channel).
✔ ‐
Updates all programs. (SOFT & DPROC FPGA & DRIVE
PULSE FPGA)
* The package VERSION is updated by this update.
PROGRAM UPDATE
―
CURRENT VERSION
--- The current package VERSION is displayed.
‐ ‐
FILE SELECT
--- It selects a package data to be updated.
‐ ‐
To Next Page
