Ikegami FA-97A - Page 151

135
HDK-99 1803 VER1 (E)
7.3 External Connections
7
SPECIFICATIONS
■
PROD INCOM Connector and ENG INCOM Connector
Used to connect an intercom headset.
Each headset type has each connector shape.
You can use the carbon type of intercom microphone or the dynamic type of that.
For switch between the carbon type and the dynamic type, use menu display. Refer to
"5. CAMERA SETTINGS and
ADJUSTMENT : Menu Configuration and content" (P85)
.
[7-pin Type]
1
2
3
7
4
5
6
Insertion Side
Camera head side : NC7FD-LX-B (Neutrik)
Cable side : XLR-7-12C
Receptacle
ecafretnI lanretxEO/InoitcnuFemaN.oN niP
①
LISTEN L (C)
Shield for intercom receiver L output
1
RET
1
2
②
LISTEN L (H)
TUO tuptuo L reviecer mocretnI
③
TALK (C)
Shield for intercom microphone input
3
RET
3
4
④
TALK (H)
NI tupni enohporcim mocretnI
⑤
COMM
DNGlanimret DNG MMOC
⑥
LISTEN R (H)
Intercom receiver R output
5
OUT
6
7
⑦
LISTEN R (C)
Shield for Intercom receiver R output
7
RET
Receiver R
Receiver L
Intercom microphone
