SD1 Series Inverters Function Parameters
-70-
Function
code
Name Description Default Modify
P07.04
STOP/RST
stop function
Select the stop function by STOP/RST.
STOP/RST
is effective in any state for the
keypad reset.
0: Only valid for the keypad control
1: Both valid for keypad and terminals control
2:
Both valid for keypad and communication
control
3: Valid for all control modes
0 ○
P07.05
Displayed
parameters 1
of running state
0x0000~0xFFFF
BIT0: Running frequency (Hz on)
BIT1: Set frequency (Hz flickering)
BIT2: Bus voltage (V on)
BIT3: Output voltage (V on)
BIT4: Output current (A on)
BIT5: Running rotation speed (rpm on)
BIT6: Output power (% on)
BIT7: Output torque (% on)
BIT8: PID reference (% flickering)
BIT9: PID feedback value (% on)
BIT10: Input terminals state
BIT11: Output terminals state
BIT12: Torque set value (% on)
BIT13: Pulse counter value
BIT14: Reserved
BIT15: PLC and the current step of Preset speed
0x03FF
○
P07.06
Displayed
parameters 2
of running state
0x0000~0xFFFF
BIT0: Analog AI1 value (V on)
BIT1: Analog AI2 value (V on)
BIT2: Analog AI3 value (V on)
BIT3: High speed pulse HDI frequency
BIT4: Motor overload percentage (% on)
BIT5: The inverter overload percentage (% on)
BIT6: Ramp frequency reference (Hz on)
BIT7: Linear speed
BIT8: AC inlet current (A on)
BIT9~15: Reserved
0x0000
