SD1 Series Inverters Function Parameters
-71-
Function
code
Name Description Default Modify
P07.07
The
parameter
selection of the
stop state
0x0000~0xFFFF
BIT0: Set frequency (Hz on, frequency flickering
slowly)
BIT1: Bus voltage (V on)
BIT2: Input terminals state
BIT3: Output terminals state
BIT4: PID reference (% flickering)
BIT5: PID feedback value (% flickering)
BIT6: Torque reference (% flickering)
BIT7: Analog AI1 value (V on)
BIT8: Analog AI2 value (V on)
BIT9: Analog AI3 value (V on)
BIT10: High speed pulse HDI frequency
BIT11: PLC and the current step of Preset speed
BIT12: Pulse counters
BIT13~BIT15: Reserved
0x00FF ○
P07.08
Frequency
display
coefficient
0.01~10.00
Displayed frequency=running frequency* P07.08
1.00
○
P07.09
Speed display
coefficient
0.1~999.9%
Mechanical rotation speed =60
x (Displayed
running frequency) × P07.09/ (
Number of motor
pole pairs)
100.0%
○
P07.10
Linear speed
displayed
coefficient
0.1~999.9%
Linear speed= Mechanical rotation
speed×P07.10
1.0%
○
P07.11
Rectifier bridge
module
temperature
-20.0~120.0°C
●
P07.12
Converter
module
temperature
-20.0~120.0°C
●
P07.13
Software
version
1.00~655.35
●
P07.14
Local
accumulative
running time
0~65535h
●
