IMT 10000 User Manual

56 Model 10000 30-foot Parts & Specifications Manual Part # 99905185
MODEL 10000 CRANE ASSEMBLY (99904925) PARTS LIST
ITEM
PART#
DESCRIPTION
DETAILS
KIT #
QTY
39.
60135833
RETAINER-1st STAGE
EXTENSION CYLINDER
2
41.
70029595
THREADED PLUG
1.00-8
2
43.
70145121
COLLAR-SHAFT 2 PIECE
7/8 in.
1
44.
70399044
TAPE -REFLECTIVE RED/
SILVER
1.25 X108.00
2
45.
70399045
TAPE -REFLECTIVE RED/
SILVER
2.00 X108.00
2
46.
70580203
WIRE ROPE ASSEMBLY
0.44 (6X25 )X130 ft LH LAY
1
48.
70734748
TRANSMITTER
(effective from 04/17/13)
SINGLE PROPORTIONAL
A/R
70734761
TRANSMITTER-RADIO
REMOTE
(effective from 04/17/13)
NON-GATED W/HORN
A/R
70734762
TRANSMITTER-RADIO
REMOTE
(effective from 04/17/13)
GATED W/HORN
A/R
49.
70734750
RECEIVER
(effective from 04/17/13)
SINGLE PROPORTIONAL
A/R
70734763
RECEIVER-RADIO REMOTE
(effective from 04/17/13)
A/R
50.
71056577
GEAR ROTATOR
0.75 BOLTS
1
51.
76039295
GASKET
#50
1
53.
71414205
PLATE-SINGLE SHEAVE
(20 #) .50 WIRE ROPE
1
54.
71570825
WINCH-PLANETARY
60.00 LB LINE PULL (A60)
1
55.
72034485
CLAMP-PLASTIC
1/4 " CABLE
9
56.
72063038
MACHINERY BUSHING
2.00 X14 GA NR
A/R
57.
72063039
MACHINERY BUSHING
2.00 X10 GA NR
A/R
58.
72661641
PIN-QUICK
5/16-2-1/16 ZINC YELLOW
1
59.
73051919
MOTOR-HYDRAULIC
1
60.
73734565
PIN-LOCK WITH HANDLE
1.00 X 3.50 WITH HAIRPIN
3
61.
73734727
VALVE BANK (WAS 73734635)
10 GPM
1
62.
77041863
SWITCH-LIMIT
DT04-4P CONN
1
63.
77441481
HARNESS-RADIO REMOTE
(WAS 77441426)
1
65.
72063116
WASHER
.75 N FLAT H ASTM F436 Z
#1
22
66.
72601629
CAP SCREW
.75-10 X 4.00 HEX HEAD GR8 Z
#1
4
67.
72601817
CAP SCREW
(effective from 02/14/13)
.75-10 X 3.25 HEX HEAD GR8 Z
#1
16
68.
72062108
NUT
.50 -20 HEX CENTER LOCK
#2
4
69.
72063132
WASHER
.50 FLAT ASTM F436
#2
4
70.
72602082
STUD
(effective from 12/06/12)
.50-13(20)X2.5 NC(NF) GR8STL
#2
4
71.
72601797
WASHER-LOCK
8MM
#3
3
72.
72602065
WASHER-FLAT
M8
#3
3
73.
72602052
CAP SCREW
M8-1.25X 16 HEX HEAD Z
#3
3
74.
72062194
NUT-STAINLESS STEEL
.25 -20 NYLOC
#4
2
75.
72063166
WASHER-FLAT
.25 R WRT 18 -8 .62 OD
STAINLESS STEEL
#4
2
76.
72601846
CAP SCREW
.25-20 X 1.25 HEX HEAD
STAINLESS STEEL
#4
2
