IMT 10000 User Manual

Chapter 4 Parts 57
MODEL 10000 CRANE ASSEMBLY (99904925) PARTS LIST
ITEM
PART#
DESCRIPTION
DETAILS
KIT #
QTY
77.
70034382
CAP-GREASE
#5
6
78.
71413185
SPRING
.105 WIRE 0.75OD 2 .875 LG
#5
1
79.
72034479
PLUG-PLASTIC
.50-13 X .50 UNC-2B
#5
2
80.
72053301
COUPLING
BLK .12
#5
1
81.
72053508
ZERK
NPT 0.12
#5
4
82.
72060000
CAP SCREW
.25-20 X .50 HEX HEAD GR5 Z
#5
2
84.
72060044
CAP SCREW
.38-16 X .75 HEX HEAD GR5 Z
#5
4
87.
72060093
CAP SCREW
.50-13 X 1.75 HEX HEAD GR5 Z
#5
12
88.
72060147
CAP SCREW
.62-11 X 1.00 HEX HEAD GR5 Z
#5
1
89.
72060206
CAP SCREW
.75-10 X 2.00 HEX HEAD GR8Z
#5
1
90.
72060639
SCREW-MACHINERY
10-24 X 1.25 ROUND HEAD
#5
2
91.
72060893
CAP SCREW
.38-16 X 3.25 HEX HEAD GR5 Z
#5
2
92.
72062000
NUT
.25-20 HEX
#5
3
93.
72062093
NUT
#8 -32 HEX ZINC
#5
2
94.
72062103
NUT
.38-16 HEX NYLOCK
#5
2
95.
72062104
NUT (effective from 04/12/13)
.25-20 HEX NYLOCK
#5
12
97.
72062106
NUT
10-24 HEX NYLOCK
#5
8
98.
72063001
WASHER
(effective from 02/28/13)
.25 FLAT
#5
17
99.
72063003
WASHER
(effective from 04/10/13)
.38 FLAT
#5
9
100.
72063010
WASHER
1.00 FLAT
#5
1
101.
72063035
M MACHINERY BUSHING
1.25 X10 GA NR
#5
2
102.
72063049
WASHER
(effective from 02/28/13)
.25 LOCK
#5
2
103.
72063051
WASHER
.38 LOCK
#5
4
104.
72063053
WASHER
(effective from 05/22/13)
.50 LOCK
#5
12
105.
72063116
WASHER
FLAT .75 N H ASTM F436 Z
#5
1
106.
72063132
WASHER
.50 FLAT ASTM F436
#5
17
107.
72063271
WASHER
# 8 W FLAT ANSI B 27. 2Z
#5
2
108.
72066129
RETAINING RING-EXTERNAL
1.25 HD
#5
2
110.
72601938
BOLT-EYE
# 8-32X 1.125
#5
1
111.
72601949
CAP SCREW
.50-13 X 1.25 SOCKET HEAD ZINC-
COATED
#5
2
112.
72602085
BOLT-SHOULDER
.38X 1.25
#5
1
113.
72661543
PIN-QUICK
#5
3
114.
72661694
BRIDLE RING
1-1/12 ID X 1/ 4-20
#5
3
115.
51395121
HOSE
AA .13 X 13.5 0 OAL (2-2)
#6
1
116.
72532355
ADAPTER
M STR/M JIC 6 6
#6
1
117.
72532356
ADAPTER
M STR/M JIC 8 6
#6
4
118.
72532357
ADAPTER
M STR/M JIC 6 8
#6
1
119.
72532358
ADAPTER
M STR/M JIC 8 8
#6
4
120.
72532359
ADAPTER
M STR/M JIC 10 8
#6
2
121.
72532361
ADAPTER
M STR/M JIC 8 10
#6
1
122.
72532670
ELBOW
M JIC/45/ F JIC 8 8
#6
1
123.
72532690
ELBOW
M JIC/90 /FJIC SW 4 4
#6
1
