IMT 10000 User Manual

58 Model 10000 30-foot Parts & Specifications Manual Part # 99905185
MODEL 10000 CRANE ASSEMBLY (99904925) PARTS LIST
ITEM
PART#
DESCRIPTION
DETAILS
KIT #
QTY
124.
72532700
ELBOW
M STR/90/ M JIC XL 6 6
#6
2
125.
72532792
ADAPTER
M STR/M JIC 8 4
#6
1
126.
72533490
ADAPTER
M BSPP/M JIC 4 4
#6
1
127.
72533583
ELBOW
M STR/45/ M JIC 8 6
#6
1
128.
72533613
ADAPTER
M STR/M JIC 10 6
#6
2
135.
93725207
KIT-CABLE GUIDE
(effective from 04/12/13)
1
136.
70734176
HOOK-SWIVEL
(effective from 04/26/13)
1
137.
60140838
COVER-VALVE BANK SIII
(effective from 03/05/13)
1
138.
60140840
BRKT-MAST VB
(effective from 03/05/13)
2
139.
72060004
CAP SCREW
(effective from 03/05/13)
0.25-20 X 1.00 HH GR5
#5
8
140.
7374472
VALVE BANK
SINGLE PROPORTIONAL
A/R
141.
77441537
HARNESS
SINGLE PROPORTIONAL
A/R
142.
60140916
PIN-TYPE NN S.0 X 9.5
(effective from 05/22/13)
1
143.
71415016
KEEPER-PIN
(effective from 05/22/13)
0.62
3
144.
60140915
PIN-TYPE NN 2.0 X 13.75
(effective from 05/22/13)
2
145.
72063055
WASHER
(effective from 05/22/13)
0.62 LOCK
#5
3
146.
72060149
CAP SCREW
(effective from 05/22/13)
0.62-11 X 1.5 HH GR5
#5
3
147.
60030486
SPACER-A2B BRACKET
(effective from 04/17/13)
2
148.
60140935
GUIDE-CABLE WEAR (WIDE)
(effective from 04/12/13)
#135
1
149.
0140938
BRKT-CABLE GUIDE (WIDE)
(effective from 04/12/13)
#135
1
150.
72060006
CAP SCREW
(effective from 04/12/13)
0.25-20 X 1.5 HH GR5
#135
2
151.
72062104
NUT (effective from 04/12/13)
0.25-20 HEX NYLOCK
#135
2
REV G 20120815
