IMT 10000 User Manual

Chapter 4 Parts 71
71570825 PARTS LIST
ITEM
PART #
DESCRIPTION
KIT #
QUANTITY
24.
CAP SCREW, SOCKET HEAD
1
25.
73540247
DUAL COUNTERBALANCE VALVE ASSEMBLY
1
26.
90° CONNECTION (CONICAL)
2
27.
BRAKE PIPE
1
28.
CAP SCREW, SOCKET HEAD
8
29.
SIDE PANEL, MOTOR SIDE
1
30.
MOTOR SIDE SUPPORT
1
31.
PLATE
2
32.
73534501
BALL BEARING
1
33.
RETAINING RING
1
34.
PLUG
1
35.
COPPER WASHER
41
1
36.
PROPELLER SHAFT
1
37.
SUN GEAR
1
38.
SUN GEAR
1
39.
WINCH DRUM
1
40.
O-RING JOINT
41
2
41.
94397459
SEAL KIT
1REF
REV. 20110124
