IMT 10000 User Manual

82 Model 10000 30-foot Parts & Specifications Manual Part # 99905185
99905018 PARTS LIST
ITEM
PART #
DESCRIPTION
DETAILS
KIT #
QUANTITY
9.
72532670
ELBO W
M JIC/45/F JIC 8 8
#1
1
10.
72532690
ELBOW
M JIC/90/F JIC SW 4 4
#1
1
11.
72532700
ELBOW
M STR/90/M JIC XLG 6 6
#1
2
12.
72532792
ADAPTER
M STR/M JIC 8 4
#1
1
13.
72533583
ELBO W
M STR/45/M JIC 8 6
#1
1
14.
72533613
ADAPTER
M STR/M JIC 10 6
#1
2
15.
72533648
SWIVEL
M JIC/90/M JIC 8 8
#1
3
16.
72534412
SWIVEL
M JIC/90/M JIC 10 10
#1
1
17.
72533490
ADAPTER
M BSPP/M JIC 4 4
#1
1
18.
51395121
HOSE-AA
.13 X 13.50 (2-2) 100R17
#1
1
19.
51396017
HOSE-FJ
.50 X 30.00 (8-8) 100R16
#1
1
20.
51397080
HOSE-FJ
.62 X 30.00 (10-10) 100R17
#1
1
21.
51397081
HOSE-FZ
.50 X 31.50 (8-8) 100R17
#1
1
22.
51397082
HOSE-FJ
.50 X 31.00 (8-8) 100R17
#1
1
23.
51396886
HOSE-FZ
.38 X 25.00 (6-6) 100R17
#1
1
24.
51396887
HOSE-FJ
.38 X 24.50 (6-6) R10017
#1
1
25.
51399077
HOSE-FJ
.38 X 29.00 (6-6) 100R17
#1
1
26.
51399078
HOSE-FZ
.50 X 30.00 (8-8) 100R17
#1
1
27.
51399072
HOSE-FJ
.38 X 22.50 (8-6) 100R17
#1
1
28.
51399073
HOSE-FZ
.38 X 25.00 (8-6) 100R17
#1
1
29.
51399228
HOSE-FJ
.38 X 18.00 (8-6) 100R17
#1
1
30.
51399229
HOSE-FJ
.38 X 22.00 (8-6) 100R17
#1
1
31.
51399074
HOSE-FJ
.25 X 32.00 (4-4) 100R2
#1
1
32.
60350141
SLEEVE-HOSE
159 X 12 CUT & SEALED
#1
3
33.
60350142
SLEEVE-HOSE
254 X 15 CUT & SEALED
#1
2
34.
60350105
SLEEVE-HOSE
WRAP AROUND, 4 IN DIA.
1
REV F 20120815

IMT 10000 Specifications

General

Brand	IMT
Model	10000
Category	Construction Equipment
Language	English
