12
LED Status Meaning
Green LED ashes once Barcode successfully read and uploaded to computer
Green LED lit BCST-33 is under standby mode
1.2. LED Indicator
The LED indicators on Inateck BCST-33 can help the user know more about the
current operation status.
1.3. Beeper
The beeper built in Inateck BCST-33 can help the user to know about the current
operation status.
Beeping Meaning
One short high note (100ms) Barcode successfully read and uploaded to computer
One long high note(400ms) Wrong Setup (on setup status, green LED stays on)
Two long high note(800ms) USB being congured (It happens when USB cable is inserted)
Three chord sound Enter setup mode (Green LED on)
Exit setup mode (Green LED o )
Two short notes (tone from low to high) Correct Setup
Two short beeps (tone from high to low) The connection between the BCST-33 and computer is disrupted.
1.3.1 Volume Control
Mute
(*)Medium Volume
Save Custom Settings
Maximum Volume
To Next Page
