Ecotec E3000
I•Guide Deactivated
Calibration (cal), internal Activated
Contrast Not inverted, setting 30
Volume 2
Minimum volume 2
Leak rate, selected, highest Automatic
Leak rate filter I-Filter
Menu PIN Deactivated, 0000
Measurement time (I•Guide) 1 second
Measuring mass 69
Peak value Deactivated, 5seconds
ECO-Check Activated
Relay outputs see interface description
RS-232 protocol ASCII
Sniffer tip, light Activated, Level 4
Sniffer tip, filter, maintenance 100hours
Recorder, gas Auto
Scaling of the recorder logarithmic
Language English
PLC outputs and inputs see interface description
Control location Local and RS-232
Search threshold 90%
Trigger value, sum (I•Guide) 10 g/a
Trigger and unit 4 g/a
Idle time (I•Guide) 3 seconds
Maintenance, sniffer tip filter 100hours
ZERO time 5 seconds
ZERO button sniffer line Activated
ZERO button basic unit Activated
