7 | Warning and error messages INFICON
64 / 104 Ecotec E3000-Operating-instructions-kina22en1-28-(2211)
7 Warning and error messages
During operation, the display shows information that supports you in the operation of
the Ecotec E3000. Measurement values are displayed along with current device
modes, operating instructions as well as warnings and error messages.
The Ecotec E3000 is equipped with extensive self-diagnosis functions. If the electronic
system detects a faulty state, the device will show this insofar as possible on the
display and will interrupt operation, if necessary.
Error messages Errors are events that the Ecotec E3000 cannot remedy itself and that force an
interruption of operation. The error message consists of a number and a descriptive
text.
After you have removed the cause of the error, start operation again with the restart
button.
Warnings Warnings warn of device states that can impair the accuracy of measurements.
Operation of the instrument is not interrupted
Confirm acknowledgment of the warning with the OK button or the right button on the
sniffer handle.
The following table displays all the warnings and error messages. It lists possible
causes for the malfunction and instructions on how to eliminate these.
Please note that work marked with an asterisk must be carried out only by service
staff that is authorized by INFICON.
No. Message Possible error sources Fault rectification
E1 Input voltage 24V on
the MC50 is too low
Fuse F1 on the wiring board is blown. Replace the fuse.*
CPU board MC50 is defective. Contact INFICON customer service.
E2 24V input voltage at
transpector is too low
Fuse F2 on the wiring board is blown. Replace the fuse.*
The Transpector is defective. Contact INFICON customer service.
E3 Input voltage 24V on
the frequency converter
is too low
Fuse F3 on the wiring board is blown. Replace the fuse.*
The turbo molecular pump is
defective.
Contact INFICON customer service.
W4 Voltage 24V on
OPTION output is too
low
Fuse F4 on the wiring board is blown. Replace the fuse.*
Power input through external wiring is
too high.
Check the wiring.
W5 Voltage 5V on sniffer
line is too low
Fuse F5 on the wiring board is blown. Replace the fuse.*
The sniffer line is defective. Replace the sniffer line.
W24 Voltage 24V of the
external display unit is
too low
Only for Ecotec E3000RC: The fuse
on driver board “External operation of
the device” is blown.
Replace the fuse.*
The RC control panel is drawing too
much power.
Contact INFICON customer service.
