INFICON Appendix | 10
Ecotec E3000-Operating-instructions-kina22en1-28-(2211) 87 / 104
10.2 Gas library
The software of the Ecotec E3000 includes a list with approx. 100 gases that can be
relevant for the refrigeration industry. These gases are saved to ROM (read only
memory) and can be selected from the list in the appropriate menus for gases and
trigger values. Mass number (measuring position), molecular mass, normalization
factor and viscosity are stored for each one. The data in this ROM cannot be changed.
The program additionally provides six empty memory spaces (user library RAM
memory). The user can save personally defined gases to them, see "Setting Custom
Gas [}49]."
The pre-set mass number (measuring position) has a gray background for each gas.
Gas Formula Other
designation
Measuring
position
(xxx amu)
Molecular
mass
(xxx.x amu)
Fragmentati
on factor
Normalizatio
n factor
(x.xExx)
Viscosity
R12B1 CF
2
ClBr Halon 1211 85 165.4 1.00 1.40E+08 0.523
87 0.32
50 0.12
129 0.15
131 0.15
R13B1 CF
3
Br Halon 1301 69 149 1.00 3.50E+07 0.852
129 0.12
131 0.12
148 0.10
150 0.10
R32 CH
2
F
2
51 52 1.00 1.90E+08 0.632
52 0.10
R41 CH
3
F 34 34 1.00 7.00E+07 0.551
33 1.00
R50 CH
4
Methane 15 16 1.00 7.00E+07 0.556
R116 C
2
F
6
69 138 1.00 7.00E+07 0.709
119 1.00
R123 C
2
HF
3
Cl
2
83 152.9 1.00 7.00E+07 0.540
85 1.00
R124 C
2
HF
4
Cl 67 136.5 1.00 7.00E+07 0.581
51 1.00
R125 C
2
HF
5
51 120 1.00 6.70E+07 0.653
69 0.27
101 0.35
