INFICON Installation | 5
Ecotec E3000-Operating-instructions-kina22en1-28-(2211) 23 / 104
CAUTION
Risk of injury due to sniffer tip
If you fall on the sniffer tip after stumbling, for example, you may injure your eyes.
► To prevent injury from accidental contact with the sniffer tip, align the sniffer tip in
the holder so that it points away from the operator.
A holder is available for the sniffer tip. The holder can be installed on the right or the
left of the device.
1 Hang the holder with its hooks in the slots on the front of the device.
2 Press the holder against the front panel of the device.
ð The holder is pulled to the front panel of the device with a magnet on its rear.
3 When not in use, fix the sniffer line in the holder so that it points away from the
operator.
5.3 Connecting the ECO-Check calibrated leak
A built-in calibrated leak (ECO-Check) and various external calibrated leaks are
available as accessories for the Ecotec E3000, see "Accessories [}85]." Please refer
to the ECO-Check installation manual on how to connect the ECO-Check.
