5 | Installation INFICON
22 / 104 Ecotec E3000-Operating-instructions-kina22en1-28-(2211)
5.2.1.3 Install and remove water protection tip
The water protection tip allows you to check test objects for leaks when they have a
small amount of surface moisture e.g. condensation moisture.
NOTICE
Risk of short circuit
Sucked in liquid can destroy the device.
► Do not suck up liquids with the instrument.
The water protection tip is screwed onto the sniffer tip end like the metal capillary filter.
The small cone seal must also be placed under the tip, see "Replacing the metal
capillary filter with the plastic capillary filter [}21]."
Fig.8: Screw water protection tip on tight
To reinstall the plastic capillary filter, see "Replacing the metal capillary filter with the
plastic capillary filter [}21]."
5.2.2 Fasten holder for sniffer line
WARNING
Danger to pacemaker wearers from magnets
The function of a pacemaker can be influenced by the magnet on the back of the
holder.
► If you wear a pacemaker, do not perform the installation yourself.
► If you wear a pacemaker, always maintain a distance of at least 10 cm from the
holder when operating the device.
