Menu item Format Description
Relay “Ready“ Low / High
Output reserved Low / High
Page 7: Analog data
AIN3 sniffer length V
AIN4 +5V II leak V
AIN5 +24V III ext. V
AIN6 +5V I sniffer V
AIN8 -15V MC50 V
AIN9 +15V MC50 V
AIN10 +24V MC50 V
AIN11 +24V I TSP V
AIN12 +24V II TMP V
Page 8: Analog data
AIN0 V
AIN0 offset V AIN0 offset
Foreline pressure mbar Foreline pressure
AIN1 V AIN1
Flow sccm Flow
Page 9: RS-232 Info
Ecotec E3000 ® Sniffer ASCII string Command sent from main
device to sniffer line
Sniffer ® Ecotec E3000 ASCII string Command sent from sniffer
line to main device
The information in the first two lines can be switched with the buttons “Sniffer” and
“Leak”:
Ecotec E3000 ® Leak ASCII string Command sent from main
device to test leak
Leak ® Ecotec E3000 ASCII string Command sent from test
leak to main device
Host ® Ecotec E3000 ASCII string Command sent from
mainframe to Ecotec
E3000
Ecotec E3000 ® Host ASCII string Command sent from
Ecotec E3000 to
mainframe
Page 10: Info field bus
IC1000 24V supply
SW version
