Replacing the battery
It is imperative to use a battery authorized by Ingenico. There is
danger of explosion if battery used is not approved by Ingenico
• Remove the terminal from its base
• Turn
it off by pressing and simultaneously for about one second
• Remove
the back cover (see section “installing battery”)
• Carefully
disconnect battery, following the instructions below
a) Unlock
the connector by pressing the locking
mechanism as indicated by F1 arrow while
pulling this connector (F2 arrow) Release
traction on it as soon as the connector comes
unclipped
b) Finish
extracting connector by tilting it slightly
(F3 arrow) to bring it away from the terminal
housing
• Inform
the terminal that battery will be replaced (*). To do so, start the
terminal without battery by fitting it on its base, or connecting terminal
power supply
• Remove
terminal from base or disconnect terminal power supply
• Connect
and install the new battery by following the instructions in
section 4.5.2 “Installing battery”
• Close
the back cover and charge the new battery. See section
«xxxxxxx0 Charging the Battery»
• In
order to preserve the environment, dispose used battery at
appropriate site in compliance with recycling legislation
(*) The terminal memorizes that there is no battery simply by powering up.
It will then correctly perform a full recharge with the next battery
