Move/3500 User Guide
Copyright© 2017 Ingenico
GPRS Terminal
Your terminal might be 2G, 3G or combined 2G/3G capable
Before connection, the mobile network status is represented by:
No icon No mobile network module or module not activated;
Mobile network module is activated but not attached to a
network.
The terminal is connected to a mobile network but the GPRS
session has not yet been established
The terminal is connected to a mobile network and the GPRS
session has been established
Maximum reception level (100%)
High reception level (75%)
Medium reception level (50%)
Low reception level (25%)
Very low reception level (<5%)
Network provider name is displayed underneath the signal
indicator
