Ingenico Move 3500 User Manual

Page 16
Move/3500 User Guide
Copyright© 2017 Ingenico
Installing a Paper Roll
• Open the paper compartment by lifting the catch located at the rear
of the terminal and pull the cover to the rear of the terminal.
• Insert the paper roll in the compartment following the directions shown
in the picture
• Pull the paper up to the top of the terminal
• Hold the paper and close the lid
• Press simultaneously on both upper corners of the paper flap, as shown
by arrows on picture, until it clips into position
When a new paper roll is inserted, tear off the first length (one
complete turn) to avoid printing on the residue of the adhesive
tape

Ingenico Move 3500 Specifications

General

Battery	Li-ion 2200mAh
Security	PCI PTS 5.x certified
Processor	ARM Cortex A5
Connectivity	Wi-Fi, Bluetooth, 3G
Operating System	Telium TETRA
Card Readers	EMV chip, NFC, magnetic stripe
Weight	320g
Display	2.4-inch QVGA (240x320 pixels)
