Move/3500 User Guide
Copyright© 2017 Ingenico
Terminal Base Overview
You should set up your base unit in a convenient location close to a power
source and, for Bluetooth terminals.
To open the base unit cover, located on the bottom of the base unit, you must
unclip an access clip and lift the cover from the base unit. To replace the cover
reverse these instructions being sure to engage all the retaining pins before the
access clips.
Terminal
guides
Terminal
charging points
Power
socket

Ingenico Move 3500 Specifications

General

Battery	Li-ion 2200mAh
Security	PCI PTS 5.x certified
Processor	ARM Cortex A5
Connectivity	Wi-Fi, Bluetooth, 3G
Operating System	Telium TETRA
Card Readers	EMV chip, NFC, magnetic stripe
Weight	320g
Display	2.4-inch QVGA (240x320 pixels)
