Ingenico Move 3500 User Manual

Page 17
Move/3500 User Guide
Copyright© 2017 Ingenico
Card Reading
Magnetic Stripe Card
The card can be read either from bottom to top or
from top to bottom, with the stripe facing the
terminal.
Use a regular movement in order to
ensure a reliable card reading.
Chip Card
Insert the card horizontally into the terminal with the chip
facing upwards.
Leave the card in position throughout the
transaction.
Contactless Card
Bring the card firmly up to the active zone above the contactless logo located
on the paper trapdoor.
Keep the card close to the contactless logo during the transaction.
The 4 virtual LEDs will light sequentially during the
transaction.

Ingenico Move 3500 Specifications

General

Battery	Li-ion 2200mAh
Security	PCI PTS 5.x certified
Processor	ARM Cortex A5
Connectivity	Wi-Fi, Bluetooth, 3G
Operating System	Telium TETRA
Card Readers	EMV chip, NFC, magnetic stripe
Weight	320g
Display	2.4-inch QVGA (240x320 pixels)
