Page 35
Omni Installation Instructions
© Mass Electronics Pty Ltd 2017Chapter 3 – Electrical Installation
Current Loop Output
Range 0mA to 20mA
Resolution 12bit @ 4096 steps
Maximum Output Voltage 9VDC @ 20mA
Accuracy ±1.5% of reading ±4LSB @ 20°C (68°F)
Dri ±200ppm/°C
Digital Duty Cycle Output
Frequency Range 60mHz to 976Hz
Duty Cycle Resolution 14bit (16383 steps)
Duty Cycle Range 0 to 100%
Switch Modes As per Digital Output specifications
Digital Pulse Output
Pulse Width Range 10µs to 268s
Pulse Resolution 16bit (65535 steps)
Switch Modes As per Digital Output specifications
Digital Output
Switch Modes
Toggle Switching (Auto) On = 12VDC O = 0V
High Side Switching On = 12VDC O = Open
Low Side Switching On = 0V O = Open
Switch Current Refer to Note
Protection
Inrush and short circuit protected Response Time: 64µs
For High Side and Toggle Switching modes, maximum available power is limited (45mA).
For Low Side Switching, each channel can switch 200mA.
Caution must be used when using Low Side Switching. For more information, contact your
Innotech representative.
Voltage Output
Range 0V to 10VDC
Resolution 12bit @ 4096 steps
Impedance ~80Ω
Maximum Current 10mA
Accuracy
±1.5% of reading ±4LSB @ 20°C (68°F) &
R
load
>10kΩ
Dri ±200ppm/°C
Programmable Point Specifications (Continued)
