Omni Installation Instructions
Page 66 © Mass Electronics Pty Ltd 2017Edition 1.2 dated 20.08.2018
Figure 4-11: Ethernet - BACnet IP Public Settings
4-4.2.4 Ethernet (BACnet IP Public)
•Specify the Network Number and UDP port or accept the defaults
•Specify the maximum number of Foreign Devices
•Specify the Public IP Address
•Enter Address information into the Distribution Table
Figure 4-12: Ethernet - Modbus TCP Settings
4-4.2.5 Ethernet (Modbus TCP)
1. Enable Modbus TCP.
2. Enter the Response Timeout (or accept the default settings).
3. Click Update to update your Omni Controller.
