Page 45
Omni Installation Instructions
© Mass Electronics Pty Ltd 2017Chapter 3 – Electrical Installation
3-4.4.2 Programmable Points
The Omni C14's programmable points (Terminals 1 to 14) provide the capability of directly interfacing
to digital input signal sources such as pushbutton switches and relay contacts.
3-4.4.3 RS-485 Comms
The Omni C14 Comms Inputs are provided for communications via BACnet MS/TP and Innotech
Protocols (Maxim / Genesis II) and for connecting to a computer (using a USB Converter), Omni
controllers and other means of communication via the RS-485 terminals.
3-4.4.4 Ethernet Port
The Omni C14 Ethernet Input provides the capability for connection to your network, connection
between Omni controllers and more.
3-4.4.5 USB
The Omni C14 has one USB Input, USB-Mini B. The USB-B connection is used for connection to a
computer.
