Inovance MD500

Appendix B
-
149
-
For example,
if function code F3-12 is not stored into EEPROM, the address is expressed as 030C;
if function code A0-05 is not stored into EEPROM, the address is expressed as 4005;
This address can only be marked as RAM. It is an invalid address when being read.
Stop/RUN Parameters
Parameter Address Description
Parameter
Address
Description
1000H
*Communication setting value
(Decimal):
-10000 to 10000
1010H PID reference
1001H Running frequency 1011H PID feedback
1002H Bus voltage 1012H PLC process
1003H Output voltage 1013H Pulse input frequency, unit: 0.01 kHz
1004H Output current 1014H Feedback speed, unit 0.1Hz
1005H Output power 1015H Remaining running time
1006H Output torque 1016H AI1 voltage before correction
1007H Running speed 1017H AI2 voltage before correction
1008H DI input indication 1018H AI3 voltage before correction
1009H DO output indication 1019H Linear speed
100AH AI1 voltage 101AH Current power-on time
100BH AI2 voltage 101BH Current running time
100CH AI3 voltage 101CH Pulse input frequency, unit: 1Hz
100DH Counting value input 101DH Communication reference
100EH Length value input 101EH Actual feedback speed
100FH Load speed 101FH Main frequency X display
– – 1020H Auxiliary frequency Y display
Note
● Communication setting value indicates percentage: 10000 corresponds to 100.00%, and -10000
corresponds to -100.00%.
● With regard to frequency, communication reference is a percentage of F0-10 (maximum frequency).
With regard to torque, communication reference is a percentage of F2-10 and A2-48 (corresponding
to motor 1 and motor 2, respectively).
Control command input to AC drive (write-only):
Command Word Address Status Denition
2000H
0001: Forward run
0002: Reverse run
0003: Forward jog
0004: Reverse jog
0005: Coast to stop
0006: Decelerate to stop
0007: Fault reset
Read AC drive state (read-only):
Command Word Address Command Word Function
3000H
0001: Forward run
0002: Reverse run
0003: Stop
Parameter lock password check: If the actual password is returned, it indicates that password check is passed.
("0000H" is returned when password is set to 0 (no password)).
