Inovance MD500

Appendix C
-
153
-
Function
Code
Name Setting Range Default Change
F0-07
Final Frequency reference
setting selection
Units position: Frequency reference selection
0: Main frequency reference
1: Main and auxiliary calculation (based on tens position)
2: Switchover between main and auxiliary
3: Switchover between main and "main & auxiliary
calculation"
4: Switchover between auxiliary and "main & auxiliary
calculation"
Tens position: main and auxiliary calculation formula
0: Main + auxiliary
1: Main - auxiliary
2: Max. (main, auxiliary)
3: Min. (main, auxiliary)
00
☆
F0-08 Preset frequency 0.00 Hz to max. frequency (F0-10) 50.00 Hz
☆
F0-09 Running direction
0: Run in the default direction (FWD/REV indicator off)
1: Run in the direction reverse to the default direction
(FWD/REV indicator on)
0
☆
F0-10 Max. frequency 50.00 Hz to 500.00 Hz 50.00 Hz
★
F0-11
Setting channel of
frequency upper limit
0: Set by F0-12
1: AI1
2: AI2
3: AI3
4: Pulse reference
5: Communication reference
0
★
F0-12
Frequency reference
upper limit
Frequency lower limit (F0-14) to max. frequency (F0-10) 50.00 Hz
☆
F0-13
Frequency reference
upper limit offset
0.00 Hz to max. frequency (F0- 10) 0.00 Hz
☆
F0-14
Frequency reference
lower limit
0.00 Hz to frequency upper limit (F0-12) 0.00 Hz
☆
F0-15 Carrier frequency 0.5kHz to 16.0kHz
Model
dependent
☆
F0-16
Carrier frequency
adjusted with load
0: Disabled
1: Enabled
1
☆
F0-17 Acceleration time 1
0.00s to 650.00s (F0-19 = 2)
0.0s to 6500.0s (F0-19 = 1)
0s to 65000s (F0-19 = 0)
Model
dependent
☆
F0-18 Deceleration time 1
0.00s to 650.00s (F0-19 = 2)
0.0s to 6500.0s (F0-19 = 1)
0s to 65000s (F0-19 = 0)
Model
dependent
☆
F0-19
Acceleration/Deceleration
time unit
0: 1s
1: 0.1s
2: 0.01s
1
★
F0-21
Frequency offset of
Auxiliary frequency
setting channel for main
and auxiliary calculation
0.00 Hz to max. frequency (F0-10) 0.00 Hz
☆
F0-22
Frequency reference
resolution
2: 0.01Hz 2
★
F0-23
Retentive of digital setting
frequency upon stop
0: Not retentive
1: Retentive
0
☆
F0-24
Motor parameter group
selection
0: Motor parameter group 1
1: Motor parameter group 2
0
★
F0-25
Acceleration/Deceleration
time base frequency
0: Maximum frequency (F0-10)
1: Frequency reference
2: 100 Hz
0
★
