Inovance MD500

Appendix C
-
154
-
Function
Code
Name Setting Range Default Change
F0-26
Base frequency for UP/
DOWN modication
during running
0: Running frequency
1: Frequency reference
0
★
F0-27
Running command +
frequency source
Units position: operating panel (keypad & display) +
frequency reference setting channel
0: No function
1: Digital setting
2: AI1
3: AI2
4: AI3
5: Pulse reference (DI5)
6: Multi-reference
7: Simple PLC
8: PID reference
9: Serial communication
Tens position: terminal I/O control + frequency reference
setting channel
Hundreds position: serial communication + frequency
reference setting channel
0000 ☆
F0-28
Serial port communication
protocol
0: Modbus protocol
1: PROFIBUS-DP or CANopen protocol
0
★
Group F1: Motor 1 Parameters
F1-00 Motor type selection
0: Common asynchronous motor
1: Variable frequency asynchronous motor
0
★
F1-01 Rated motor power 0.1 to 1000.0 kW
Model
dependent
★
F1-02 Rated motor voltage 1 to 2000 V
Model
dependent
★
F1-03 Rated motor current
0.01 to 655.35 A (AC drive power ≤ 55 kW)
0.1 to 6553.5 A (AC drive power > 55 kW)
Model
dependent
★
F1-04 Rated motor frequency 0.01 Hz to max. frequency
Model
dependent
★
F1-05 Rated motor speed 1 to 65535 RPM
Model
dependent
★
F1-06 Stator resistance
0.001 to 65.535 Ω (AC drive power ≤ 55 kW)
0.0001 to 6.5535 Ω (AC drive power > 55 kW)
Auto-tuning
parameter
★
F1-07 Rotor resistance
0.001 to 65.535 Ω (AC drive power ≤ 55 kW)
0.0001 to 6.5535 Ω (AC drive power > 55 kW)
Auto-tuning
parameter
★
F1-08
Leakage inductive
reactance
0.01 to 655.35 mH (AC drive power ≤ 55 kW)
0.001 to 65.535 mH (AC drive power > 55 kW)
Auto-tuning
parameter
★
F1-09
Mutual inductive
reactance
0.1 to 6553.5 mH (AC drive power ≤ 55 kW)
0.01 to 655.35 mH (AC drive power > 55 kW)
Auto-tuning
parameter
★
F1-10 No-load current
0.01 to F1-03 (AC drive power ≤ 55 kW)
0.1 to F1-03 (AC drive power > 55 kW)
Auto-tuning
parameter
★
F1-27
Encoder pulses per
revolution
1 to 65535 1024
★
F1-28 Encoder type
0: ABZ incremental encoder
2: Resolver
0
★
F1-30
A/B phase sequence of
ABZ incremental encoder
0: Forward
1: Reserve
0
★
F1-34
Number of pole pairs of
resolver
1 to 65535 1
★
F1-36
Encoder wire-break fault
detection time
0.0s: No detection
0.1s to 10.0s
0.0s
★
