Appendix C
-
163
-
Function
Code
Name Setting Range Default Change
F7-04
LED display running
parameters 2
0000 to FFFF
Bit00: PID feedback
Bit01: PLC stage
Bit02: Pulse reference (kHz)
Bit03: Running frequency 2 (Hz)
Bit04: Remaining running time
Bit05: AI1 voltage before correction (V)
Bit06: AI2 voltage before correction (V)
Bit07: AI3 voltage before correction (V)
Bit08: Motor speed
Bit09: Current power-on time (H)
Bit10: Current running time (Min)
Bit11: Pulse reference (Hz)
Bit12: Communication reference
Bit13: Encoder feedback speed (Hz)
Bit14: Main frequency X display (Hz)
Bit15: Auxiliary frequency Y display (Hz)
0
☆
F7-05 Display stop parameters
0000 to FFFF
Bit00: Frequency reference (Hz)
Bit01: Bus voltage (V)
Bit02: DI state
Bit03: DO state
Bit04: AI1 voltage (V)
Bit05: AI2 voltage (V)
Bit06: AI3 voltage (V)
Bit07: Count value
Bit08: Length value
Bit09: PLC stage
Bit10: Load speed
Bit11: PID reference
Bit12: Pulse reference (kHz)
0
☆
F7-06
Load speed display
coefcient
0.0001 to 6.5000 1.0000
☆
F7-07
Heatsink temperature of
AC Drive
-20°C to 120°C -
●
F7-08 Product number - -
●
F7-09
Accumulative running
time
0h to 65535h -
●
F7-10
Performance software
version
- -
●
F7-11 Function software version - -
●
F7-12
Number of decimal places
for load speed display
Units position: Number of decimal places for U0-14
0: No decimal place
1: One decimal places
2: Two decimal places
3: Three decimal places
Tens position: Number of decimal places of U0-19/U0-29
1: One decimal places
2: Two decimal places
21
☆
F7-13
Accumulative power-on
time
0 to 65535 h -
●
F7-14
Accumulative power
consumption
0 to 65535 kWh -
●
Group F8: Auxiliary Functions
F8-00 Jog frequency reference 0.00 Hz to max. frequency 2.00 Hz
☆
F8-01 Jog acceleration time 0.0s to 6500.0s 20.0s
☆
